Bootlace Ferrules
39 codes from Bl0050 to UBL5000. Packs of 100, 50, 25 or 10.
3 products
Products
22 sizes
Bl0050, Bl0075, BL0100 +19 more
0.5 mm² to 95 mm² wire · lengths 8 mm to 25 mm · packs of 100, 50, 25 or 10
8 sizes
BLT0075, BLT0100, BLT0150 +5 more
2 × 0.75 mm² to 2 × 16 mm² wire · lengths 8 mm to 14 mm · packs of 100, 50 or 25
9 sizes
UBL0150, UBL0250, UBL0400 +6 more
1.5 mm² to 50 mm² wire · lengths 8 mm to 22 mm · packs of 100, 50, 25 or 10
No products match those filters. Try a different code, or search the whole range.
Specifications
Insulated ferrules
| Low Smoke Halogen Free | Yes |
|---|
| Ferrule material | Copper, tin plated |
|---|
| Collar | Nylon, low smoke halogen free |
|---|
| Temperature range | −55 to 105 °C |
|---|
| Cable | For copper cable only |
|---|
| Rated voltage | 300 V |
|---|
| Wire range | 0.5–95 mm², one wire per ferrule |
|---|
| Colour code | By wire size, see the size chart |
|---|
| Compliance | RoHS, REACH |
|---|
Twin-entry ferrules
| Low Smoke Halogen Free | Yes |
|---|
| Ferrule material | Copper, tin plated |
|---|
| Collar | Nylon, low smoke halogen free |
|---|
| Temperature range | −55 to 105 °C |
|---|
| Cable | For copper cable only |
|---|
| Rated voltage | 300 V |
|---|
| Wire range | 2 × 0.75 to 2 × 16 mm², two wires per ferrule |
|---|
| Colour code | By wire size, see the size chart |
|---|
| Compliance | RoHS, REACH |
|---|
Uninsulated ferrules
| Ferrule material | Copper, tin plated |
|---|
| Rated voltage | 300 V |
|---|
| Wire range | 1.5–50 mm², one wire per ferrule |
|---|
| Compliance | RoHS, REACH |
|---|
